| Brand Name : | Honeywell |
| Model Number : | 51198947-100F |
| Price : | USD |
| Payment Terms : | T/T |
| Delivery Time : | 3-5 days |
Ironman Technology Co.,LTD
Featured Brand:
● HONEYWELL ● AB ● OMRON ●SIEMENS ●SCHNEIDER
● ROSEMOUNT● ABB ● NOTIFIER ●MTL ● GE ●And many more !
51198947-100F Power Supply Cherokee International ACX6 Honeywell pwr supply
Lead time:3-5 days
New with one year warranty
The power supply is an AC input, AC/DC output power supply intended
for use in Honeywell UCN (PM, APM or HPM) equipment cabinets.
The supply operates from line voltage 85 to 264 VAC, or (48 Vdc)
batteries, and is CE-compliant.
The DC output is nominally rated at the output pins to be 25.25 Vdc
at a 10 amp load when powered from the AC Line, and 24.25Vdc when
powered from 48V battery. The design also includes a charging
circuit for the 48V battery. There is also a nominal 6 Vac,
line-frequency output rated at 35 milliamps load, to provide line
frequency synchronization.
The full load operating temperature range is -20 to +55 deg C.
Derating of the output load capability applies linearly above 55¦C
at 0.5 amp/deg C to a maximum temperature of +65 deg C.
Two or more power supplies may be used with their outputs
paralleled.
The supply is in compliance with all the applicable directives of
the European Economic Community (EEC).
|
|
