LS2D4K Honeywell Limit Switches 1NC 1NO SPDT 10A Top Roller Plunger
Lead time:3-5 days
New with one year warranty
FEATURES
• 316 Series stainless steel actuating heads and body with stainless steel screws
• Designed to IP 65/66/67 and NEMA 1, 3, 3R, 4, 4X, 6, 6P, 12, and 13
• Diaphragm seal between head and body provides an extra degree of sealing
• Fluorocarbon seals standard for chemically harsh environments and/or higher temperature applications (121 °C/250 °F)
• Optional fluorosilicone seals for low temperature (-40 °C/-40 °F) applications
• Available with 1NC/1NO or 2NC/2NO double break contacts. Same polarity for each pole (Za)
• Side rotary head with center neutral or sequential switch design available
• Actuator heads can be field rotated to any of four positions 90° apart
• Side rotary heads are factory adjusted for CW and CCW actuation of the switch. Heads can be field adjusted for CW only or CCW only to actuate the switch
• CCC, CE, CSA, and UL certifications for global acceptance
POTENTIAL APPLICATIONS
• Food processing plants • Petrochemical plants
• Power generating plants • Pulp and paper mills
• Shipboard and dockside locations • Transportation hubs and facilities
• Water treatment and wastewater treatment facilities
VALUE TO CUSTOMERS
• Harsh-duty stainless steel switch withstands many tough environments including dust, dirt, grime, heat, and washdown areas
• Variety of actuator heads and switch options
• Threaded conduit or factory wired
• Silver contacts or optional gold-plated contacts
• Made in the USA
Actuator Type | Roller Plunger | |
Mounting Type | Chassis Mount | |
Termination Style | Screw Terminal | |
Ingress Protection | - | |
Features | Stainless Steel | |
Operating Force | 1814gf | |
Release Force | - | |
Pretravel | 0.070" (1.78mm) | |
Differential Travel | 0.015" (0.38mm) | |
Overtravel | 0.190" (4.8mm) | |
Operating Temperature | -12°C ~ 121°C | |
Operating Position | 2.200" (55.9mm) | |
Electrical Life |
|
|
